RP2040 Breakout — KiCad Bridge Pipeline Demo

RP2040 Breakout Pipeline Demo·Adom

RP2040 breakout board pushed end-to-end through the Adom KiCad bridge molecule pipeline: kicad_export_molecule (STEP + ray-traced silkscreen renders on a GPU VM) -> step2glb color-preserving GLB -> adom-molecule. Annotated silks (U1/C1-C5/Y1/J1), USB-C, 12 MHz crystal, QFN-56 RP2040.

bmi270-molecule

BMI270·Bosch Sensortec

Bosch BMI270 6-axis IMU (3-axis accelerometer + 3-axis gyroscope) packaged as an Adom molecule — anchored GLB, machine-pin wings, KiCad source.

bme690-molecule

BME690·Bosch Sensortec

Bosch BME690 4-in-1 environmental sensor (gas, pressure, humidity, temperature) packaged as an Adom molecule — anchored GLB, machine-pin wings, KiCad source.

Teazzers Taprite Solenoid 638-0031 v1

Teazzers Taprite Solenoid 638-0031 v1

Electromechanical carrier molecule for the Taprite 638-0031 DC 24V solenoid valve — 198×102 mm, 6 machine contacts (2× GND, 2× VCC), 4 alignment machine pins. Designed for the Teazzers beverage dispen

rp2350a-mini

RP2350A_Mini·Adom·molecule-module

General-purpose RP2350A castellated module — 20×36 mm, dual-core Arm Cortex-M33 / Hazard3 RISC-V MCU with 16 Mbit QSPI flash, USB, UART, SWD debug, and 4 ADC channels. 26 user-programmable GPIO/ADC pins on castellated machine contacts (44 contacts + 4 corner machine pins). Drop-in MCU module for Adom workcell designs.

Teazzers - Taprite: Solenoid Multi-Carrier

Teazzers_Taprite_Solonoid-638-0031_Multicarrier_v1.0·Teazzers x Taprite·molecule-carrier

Teazzers_Taprite_Solonoid-638-0031_Multicarrier_v1.0 - Carrier board for (4) Taprite Solenoid (638-0031) breaking out [Power]. Includes red "power on" LEDs. Drive current = 0.7A/solenoid

Teazzers - Taprite: Solenoid Carrier

Teazzers_Taprite_Solonoid-638-0031_v2.0·Teazzers x Taprite·molecule-carrier

Teazzers_Taprite_Solonoid-638-0031_v2.0 - Carrier board for single Taprite Solenoid (638-0031) breaking out [Power]. Includes red "power on" LED. Solenoid drive current = 0.7A

taprite-solonoid-wiretest

Taprite Solonoid molecule (KiCad) wiring-pipeline test: anchored GLB + .kicad_pcb. Validates KiCad publish->import->footprint->wiring end to end.

I2S: Carrier

I2S_Carrier·Adom·molecule-carrier

I2S_Carrier_v1.0: Carrier for I2S MEMs Microphones, standardized to fit all MEMs varients. Jumper selects Left or Right.

bmv080-molecule

BMV080·Bosch Sensortec

Bosch BMV080 ultra-compact PM2.5 particulate-matter sensor packaged as an Adom molecule — anchored GLB, machine-pin wings, FPC connector, KiCad source.

piprobe-v1-3

PiProbe_v1.3·Adom·molecule-module

PiProbe_v1.3: RP2040-based SWD debug probe molecule — 28×20 mm, CMSIS-DAP with SWD debug + UART passthrough, 9 machine contacts + 4 machine pins. Runs Raspberry Pi Debugprobe firmware. Flash and debug

piprobe-occt-unified

PiProbe OCCT single-source bundle (GLB + footprint w/ per-pad Z + symbol).

piprobe-occt-molecule

PiProbe molecule — full OCCT molecule-mode output (auto-anchor FL->origin, gold PBR pins, join+Draco) from a KiCad-10 desktop STEP export. End-to-end pipeline validation artifact.

rp2350a-mini-wiretest

RP2350A Mini molecule (KiCad) wiring-pipeline test: anchored GLB + .kicad_pcb. Validates KiCad publish->import->footprint->wiring end to end.

piprobe-wiretest

PiProbe molecule (KiCad-origin) wiring-pipeline test: KiCad GLB + .kicad_pcb. Validates the KiCad publish -> import -> footprint -> wiring path end to end.

molecule-ap2114h-wiretest

AP2114H molecule (KiCad) wiring-pipeline test: anchored GLB + .kicad_pcb.

taprite-mosfet-wiretest

Taprite MOSFET molecule (KiCad) wiring-pipeline test: anchored GLB + .kicad_pcb. Validates KiCad publish->import->footprint->wiring end to end.

usb2532-hub-c-wiretest

USB2532 HUB molecule (KiCad) wiring-pipeline test: anchored GLB + .kicad_pcb. Validates KiCad publish->import->footprint->wiring end to end.
