component

taprite-mosfet-wiretest

Public Unreviewed

by Drew Owens

Taprite MOSFET molecule (KiCad) wiring-pipeline test: anchored GLB + .kicad_pcb. Validates KiCad publish->import->footprint->wiring end to end.

moleculekicadteazzerstest
Overview Files Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity
taprite-mosfet-wiretest

Taprite MOSFET wiretest (KiCad)

End-to-end KiCad molecule pipeline test (publish -> import -> footprint -> wiring) in Hydrogen. Source: Caleb Taprite MOSFET (KiCad). Ships the anchored GLB and the .kicad_pcb; the importer feeds the board to the converter to generate machine-pin/contact footprint JSON for 3D-editor wiring. Pipeline validation only.

Files

model.glb 3D Model (GLB) board.kicad_pcb KICAD_PCB File hero.png Image package.json Data File
