PiProbe molecule (KiCad-origin) wiring-pipeline test: KiCad GLB + .kicad_pcb. Validates the KiCad publish -> import -> footprint -> wiring path end to end.

moleculekicadpiproberp2040test
Overview Files Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity
piprobe-wiretest

PiProbe wiretest (KiCad)

End-to-end test of the KiCad molecule pipeline (publish → import → footprint → wiring) in Hydrogen, mirroring the Fusion BHI385 test. Source: Caleb's PiProbe_Molecule_v1.3 (KiCad). Ships the KiCad-exported GLB and the .kicad_pcb; the importer feeds the .kicad_pcb to the board converter (/api/convert-pcb) to generate the machine-pin/contact footprint JSON used for 3D-editor wiring. Pipeline validation only.

Files

piprobe.glb 3D Model (GLB) piprobe.step STEP CAD Model hero.png Image package.json Data File piprobe.kicad_pcb KICAD_PCB File
