PiProbe molecule — full OCCT molecule-mode output (auto-anchor FL->origin, gold PBR pins, join+Draco) from a KiCad-10 desktop STEP export. End-to-end pipeline validation artifact.

moleculekicadpiprobeoccttest
Overview Files Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity
piprobe-occt-molecule

PiProbe — OCCT molecule-mode

PiProbe molecule produced by the new OCCT service-occt molecule-mode pipeline (/convert?molecule=true): STEP exported from KiCad 10 (with the Adom existing-v2.1 3D library) → OCCT STEP→GLB → auto-anchor (front-left machine pin → origin, up-axis auto-detected) → gold PBR on pins/contacts → join + Draco. End-to-end pipeline validation artifact (anchor verified: FL=MP2, up=Z).
