component

usb2532-hub-c-wiretest

Public Unreviewed

by Drew Owens

USB2532 HUB molecule (KiCad) wiring-pipeline test: anchored GLB + .kicad_pcb. Validates KiCad publish->import->footprint->wiring end to end.

moleculekicadteazzerstest
Overview Files Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity
usb2532-hub-c-wiretest

USB2532 HUB wiretest (KiCad)

End-to-end KiCad molecule pipeline test (publish -> import -> footprint -> wiring) in Hydrogen. Source: Caleb USB2532 HUB (KiCad). Ships the anchored GLB and the .kicad_pcb; the importer feeds the board to the converter to generate machine-pin/contact footprint JSON for 3D-editor wiring. Pipeline validation only.

Files

model.glb 3D Model (GLB) usb2532.glb 3D Model (GLB) usb2532.step STEP CAD Model board.kicad_pcb KICAD_PCB File hero.png Image package.json Data File
