Hardware

Hardware: components, molecules, projects, and equipment with symbols, footprints, and 3D models.

4 hardware pages matching

All5Components4Molecules1
Sort by: Recent Popular A-Z
Tagsmcu×stm323arm2microcontroller2stmicroelectronics2adom1adom-modular1blue-pill1cortex-m31cortex-m331cortex-m41cortex-m71lqfp-1441lqfp-481lqfp-641rp20401st1stm32h51
Filters: kind: component× tag: mcu× Clear all
hardware v1.0.1 adom

STM32H563RGTx

STM32H563RGTx·STMicroelectronics·LQFP-64

3DSymFp

STMicroelectronics STM32H563RGTx — Arm Cortex-M33 microcontroller (250 MHz, 2 MB flash, 640 KB SRAM) with Ethernet MAC. LQFP-64 (10x10mm, 0.5mm pitch).

adom · 4d ago
componentmcumicrocontrollerstm32
adom-wiki pkg install adom/stm32h563rgtx
hardware v0.1.1 adom

STM32H745ZITx

STM32H745ZITx·STMicroelectronics·LQFP-144

STMicroelectronics STM32H745ZI — dual-core Arm Cortex-M7 (480 MHz) + Cortex-M4 (240 MHz) STM32H7 microcontroller. LQFP-144 (20x20mm, 0.5mm pitch), 2 MB flash / 1 MB RAM.

adom · 4d ago
componentmcustm32stm32h7
adom-wiki pkg install adom/stm32h745zitx
hardware v0.2.2 adom

STM32F103C8T6 - Arm Cortex-M3 MCU (Blue Pill)

STM32F103C8T6·STMicroelectronics·LQFP-48 7x7mm P0.5mm

3DSymFpDS

STMicroelectronics mainstream Arm Cortex-M3 MCU. 72 MHz, 64 KB Flash, 20 KB SRAM, USB, CAN, LQFP-48. The workhorse Blue Pill microcontroller.

adom · 18d ago
componentmicrocontrollermcuarm
adom-wiki pkg install adom/stm32f103c8t6
hardware v0.1.0 adom

RP2040 Test Board

RP2040TestBoard·Adom·MCU board (Adom modular)

3D

RP2040 test board (SC0914) - 3D model with the real TOP-COPPER routing overlaid so you can see the traces

adom · 27d ago
adomadom-modularcomponentrp2040
adom-wiki pkg install adom/rp2040-test-board
