LMV331IDBVR
LMV331IDBVR — IC. Canonical adom-lbr JSON + KiCad symbol/footprint/3D. Used on the USB3-to-Ethernet Data-Only Molecule.
adom-wiki pkg install barrett-land/lmv331idbvr
TL331LV
TL331LV - single low-voltage comparator, SOT-23-5, with REVERSED input pinout (IN- = pin 1, IN+ = pin 3). Canonical adom-lbr JSON + KiCad symbol/footprint/3D. Used on the USB3-to-Ethernet Data-Only Molecule.
adom-wiki pkg install barrett-land/tl331lv
M93C66-WMN6TP
M93C66-WMN6TP — IC. Canonical adom-lbr JSON + KiCad symbol/footprint/3D. Used on the USB3-to-Ethernet Data-Only Molecule.
adom-wiki pkg install barrett-land/m93c66-wmn6tp
HD3SS3212IRKSR
HD3SS3212IRKSR — IC. Canonical adom-lbr JSON + KiCad symbol/footprint/3D. Used on the USB3-to-Ethernet Data-Only Molecule.
adom-wiki pkg install barrett-land/hd3ss3212irksr
tja1051t-3-118
NXP Semiconductors TJA1051T/3,118. High-speed CAN transceiver, 5 V, SOIC-8
adom-wiki pkg install adom/tja1051t-3-118
ads124s08ipbsr
Texas Instruments ADS124S08IPBSR. 24-bit, 4-kSPS, 12-channel delta-sigma ADC with PGA and reference, HTQFP-32
adom-wiki pkg install adom/ads124s08ipbsr
stm32g431rbt6
STMicroelectronics STM32G431RBT6. Arm Cortex-M4F MCU, 170 MHz, 128 KB flash, 32 KB RAM, LQFP-64
adom-wiki pkg install adom/stm32g431rbt6
NCP1117ST33T3G
NCP1117ST33T3G — IC. Canonical adom-lbr JSON + KiCad symbol/footprint/3D. Used on the USB3-to-Ethernet Data-Only Molecule.
adom-wiki pkg install barrett-land/ncp1117st33t3g
tps5430ddar
Texas Instruments TPS5430DDAR. 3 A step-down SWIFT DC-DC converter, 5.5-36 V input, SO PowerPAD-8
adom-wiki pkg install adom/tps5430ddar
tps7a0533pdbzr
Texas Instruments TPS7A0533PDBZR. 200 mA ultra-low-Iq LDO regulator, fixed 3.3 V, SOT-23-3
adom-wiki pkg install adom/tps7a0533pdbzr
SuperSpeed USB 3.1 to 10/100/1000 Ethernet Controller - LAN7800
Microchip LAN7800 — single-chip SuperSpeed USB 3.1 Gen 1 to 10/100/1000 Gigabit Ethernet controller with integrated USB device controller + PHY, Ethernet MAC, and Gigabit PHY. QFN-48 in 7x7 mm (Y9X) and 6x6 mm (VSX).
adom-wiki pkg install adom/lan7800
1 A Low-Dropout Regulator UMW - AMS1117
UMW / Youtai Semiconductor AMS1117 - second-source three-terminal 1 A low-dropout linear regulator. Fixed 1.2/1.5/1.8/2.5/3.3/5.0 V or adjustable, in SOT-223-3L, TO-252-2L and SOT-89-3L.
adom-wiki pkg install adom/umw-ams1117
1 A Low-Dropout Regulator AMS - AMS1117
Advanced Monolithic Systems AMS1117 - the original three-terminal 1 A low-dropout linear regulator. Fixed 1.5/1.8/2.5/2.85/3.3/5.0 V or adjustable, in SOT-223, TO-252 (DPAK) and 8-lead SOIC.
adom-wiki pkg install adom/ams-ams1117
[DEPRECATED] 1 A Low-Dropout Regulator - AMS1117 → ams-ams1117 / umw-ams1117
DEPRECATED - split by manufacturer. Use adom/ams-ams1117 (Advanced Monolithic Systems: 1.5-5.0 V incl. 2.85 V, SOT-223/TO-252/SO-8) or adom/umw-ams1117 (UMW/Youtai: 1.2-5.0 V, SOT-223/TO-252/SOT-89). The two vendors ship different voltage lineups, different packages and materially different limits.
adom-wiki pkg install adom/ams1117
