Texas Instruments TPS7A0533PDBZR. 200 mA ultra-low-Iq LDO regulator, fixed 3.3 V, SOT-23-3

componentictexas
Overview Files Discover Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity

3D Model

Open in new tab ↗

README

markdown

TPS7A0533PDBZR

Texas Instruments TPS7A0533PDBZR - 200 mA ultra-low-Iq LDO regulator, fixed 3.3 V, SOT-23-3.

| Manufacturer | Texas Instruments | | MPN | TPS7A0533PDBZR | | Category | ic | | Summary | 200 mA ultra-low-Iq LDO regulator, fixed 3.3 V, SOT-23-3 |

Datasheet

Ships the KiCad symbol, footprint, a color-preserving GLB 3D model, and an adom-lbr JSON (with generated Fusion 360 .lbr).

Symbol & Footprint

Schematic Symbol

Open full view ↗

PCB Footprint

Open full view ↗
