TPS5430DDAR

Texas Instruments TPS5430DDAR - 3 A step-down SWIFT DC-DC converter, 5.5-36 V input, SO PowerPAD-8.

| Manufacturer | Texas Instruments | | MPN | TPS5430DDAR | | Category | ic | | Summary | 3 A step-down SWIFT DC-DC converter, 5.5-36 V input, SO PowerPAD-8 |

Datasheet

Ships the KiCad symbol, footprint, a color-preserving GLB 3D model, and an adom-lbr JSON (with generated Fusion 360 .lbr).

Symbol & Footprint

Schematic Symbol

Open full view ↗
Loads on click. Unloads only if this page sits in the background.

PCB Footprint

Open full view ↗
Loads on click. Unloads only if this page sits in the background.
