ADS124S08IPBSR

Texas Instruments ADS124S08IPBSR - 24-bit, 4-kSPS, 12-channel delta-sigma ADC with PGA and reference, HTQFP-32.

| Manufacturer | Texas Instruments | | MPN | ADS124S08IPBSR | | Category | ic | | Summary | 24-bit, 4-kSPS, 12-channel delta-sigma ADC with PGA and reference, HTQFP-32 |

Ships the KiCad symbol, footprint, a color-preserving GLB 3D model, and an adom-lbr JSON (with generated Fusion 360 .lbr).

Symbol & Footprint

Schematic Symbol

Open full view ↗

PCB Footprint

Open full view ↗
