component
wireless-link Library
Public Made by Adomby adom
Component library for the wireless-link molecule — the components used on the board, linked as dependencies.
Symbol & Footprint
Schematic Symbol
Open full view ↗wireless-link Library
Component library for the wireless-link molecule. Each component type used on the board is linked as a dependency.
Components
| Ref(s) | Part | Wiki page |
|---|---|---|
| MC1–MC40 | Adom machine contact (medium) | adom/machinecontactmedium |
| MP1–MP4 | Adom machine pin (large, press-fit v3) | adom/machinepinlargestandard |
| J2, J4 | Pin header 1x08 2.54 mm vertical | adom/pinheader-1x08-p2-54mm-vertical |
| J1, J3 | Pin header 1x12 2.54 mm vertical | adom/pinheader-1x12-p2-54mm-vertical |
H1–H10 are 2.5 mm mounting holes (mechanical, no component page).
Files
wireless-link.kicad_sym— the board's schematic symbols, extracted from the project's embeddedlib_symbols.library.step— representative 3D file (large machine pin), reused fromadom/machinepinlargestandard.
Provenance — symbol library. Generated from the
lib_symbolsblock embedded inwireless-link.kicad_sch(pulled from Noah's PC 2026-07-09), wrapped as akicad_symbol_lib. Not exported from KiCad's symbol editor.
