Pin Header 1x12 2.54mm Vertical

Public Made by Adom

by adom

Generic 12-position single-row 2.54 mm pitch vertical through-hole pin header. KiCad standard symbol (Conn_01x12), footprint (PinHeader_1x12_P2.54mm_Vertical) and 3D model.

connectorpin-headerthrough-hole2.54mm
Overview Files Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity

3D Model

Symbol & Footprint

Schematic Symbol

Open full view ↗

PCB Footprint

Open full view ↗

Pin Header 1x12 — 2.54 mm Vertical

Generic 12-position single-row pin header, 2.54 mm pitch, vertical, through-hole. Published as a supporting component for the wireless-link molecule.

Files

  • PinHeader_1x12_P2.54mm_Vertical.kicad_sym — KiCad symbol (Connector_Generic:Conn_01x12)
  • PinHeader_1x12_P2.54mm_Vertical.kicad_mod — KiCad footprint (Connector_PinHeader_2.54mm:PinHeader_1x12_P2.54mm_Vertical)
  • PinHeader_1x12_P2.54mm_Vertical.step / .glb — 3D model

Provenance. Symbol and footprint extracted from the wireless-link KiCad 9 project (KiCad standard library parts embedded in the schematic/PCB); STEP from the official KiCad packages3D library (gitlab.com/kicad/libraries); GLB converted with step2glb. This is a generic part, not manufacturer-specific.

Files

PinHeader_1x12_P2.54mm_Vertical.glb 3D Model (GLB) PinHeader_1x12_P2.54mm_Vertical.step STEP CAD Model PinHeader_1x12_P2.54mm_Vertical.kicad_mod KiCad Footprint PinHeader_1x12_P2.54mm_Vertical.kicad_sym KiCad Symbol hero.png Image package.json Data File
