BMA580 Molecule Library
Public Made by Adomby adom
Component library for the BMA580 Molecule board — the components used on the board, linked as dependencies.
Symbol & Footprint
Schematic Symbol
Open full view ↗BMA580 Molecule Library
Component library for the BMA580 Molecule board. Each component used on the board is linked as a dependency, so the Adom Project Manager can list them with symbol + footprint + 3D.
Components
| Ref(s) | Part | Wiki page |
|---|---|---|
| AC1 | Bosch BMA580 accelerometer | adom/bma580-561000 |
| MC1–MC3 | Adom machine contact (medium) | adom/machinecontactmedium |
| MP1–MP4 | Adom machine pin (medium short) | adom/machinepinmediumshort |
| C1 | 100 nF 0402 (Samsung CL05B104KO5NNNC, LCSC C1525) | barrett-land/cl05b104ko5nnnc |
| R1 | 5.1 kΩ 0402 (UNI-ROYAL 0402WGF5101TCE, LCSC C25905) | barrett-land/0402wgf5101tce |
Not yet on the wiki: D1 — 0402 LED (LCSC C130725). It has no component page, so it is not linked as a dependency and won't appear in the Manager's component list until one is published.
Files
BMA580.kicad_sym— the board's schematic symbols, extracted from the project's embeddedlib_symbols.library.step— representative 3D file (machine pin), reused fromadom/machinepinmediumshort.
Provenance — symbol library.
BMA580.kicad_symwas generated from thelib_symbolsblock embedded inBMA580.kicad_sch(pulled from Noah's PC on 2026-07-08), wrapped as akicad_symbol_lib. It was not exported from KiCad's symbol editor. The project has no project-local.pretty; footprints are embedded in the pushedBMA580.kicad_pcbon the board page.
