Reset Switch v2
The TSB013A4318A02 molecule is a breakout of the BZCN SMD tactile switch rated at 12 V DC and 50 mA, featuring a rectangular actuator approximately 6 mm × 3.5 mm, an operating force of ~180 gf, and a vertical standing‑paste surface‑mount package (~4.3 mm high).
NSF Relevance
This molecule provides a ready-to-use tactile switch for rapid prototyping, allowing users to quickly integrate momentary input functionality into circuits.
Science Drivers
component_testing, xrp_platform
Created by: abcdefgh
Version: v1
Category: other
Files
bom.csv
CSV File
cpl.csv
CSV File
Reset_Switch_v3_gerbers.zip
ZIP File
