STMicroelectronics STM32H563RGTx — Arm Cortex-M33 microcontroller (250 MHz, 2 MB flash, 640 KB SRAM) with Ethernet MAC, used as the host controller on the Large Automotive Eth Switch Molecule. LQFP-64

componentmcumicrocontrollerstm32stm32h5cortex-m33stlqfp-64
Overview Files Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity

3D Model

Symbol & Footprint

Schematic Symbol

Open full view ↗

PCB Footprint

Open full view ↗

STM32H563RGTx

STMicroelectronics STM32H563RGTx — Arm Cortex-M33 microcontroller (250 MHz, 2 MB flash, 640 KB SRAM) with Ethernet MAC, used as the host controller on the Large Automotive Eth Switch Molecule. LQFP-64 (10x10mm, 0.5mm pitch).

Part of the adom/large-automotive-eth-switch-molecule automotive Ethernet toolboard.

Contents

File Purpose
stm32h563rgtx.kicad_sym KiCad schematic symbol
LQFP-64_10x10mm_P0.5mm.kicad_mod KiCad footprint
LQFP-64_10x10mm_P0.5mm.step 3D model (STEP)
stm32h563rgtx.glb 3D model (GLB, wiki viewer)
stm32h563rgtx.adom-lbr.json Canonical adom-lbr library JSON

Files

stm32h563rgtx.glb 3D Model (GLB) LQFP-64_10x10mm_P0.5mm.step STEP CAD Model LQFP-64_10x10mm_P0.5mm.kicad_mod KiCad Footprint stm32h563rgtx.kicad_sym KiCad Symbol hero.png Image package.json Data File stm32h563rgtx.adom-lbr.json Data File
