SI3437DV-T1-GE3

Vishay Siliconix SI3437DV-T1-GE3 - P-channel power MOSFET, TSOP-6.

| Manufacturer | Vishay Siliconix | | MPN | SI3437DV-T1-GE3 | | Category | transistor | | Summary | P-channel power MOSFET, TSOP-6 |

Ships the KiCad symbol, footprint, a color-preserving GLB 3D model, and an adom-lbr JSON (with generated Fusion 360 .lbr).

Symbol & Footprint

Schematic Symbol

Open full view ↗

PCB Footprint

Open full view ↗
