JST S10B-PH-SM4-TB(LF)(SN). 10-circuit PH-series 2.0 mm-pitch top-entry SMT wire-to-board header
3D Model
Open in new tab ↗
README
markdownS10B-PH-SM4-TB(LF)(SN)
JST S10B-PH-SM4-TB(LF)(SN) - 10-circuit PH-series 2.0 mm-pitch top-entry SMT wire-to-board header.
| Manufacturer | JST | | MPN | S10B-PH-SM4-TB(LF)(SN) | | Category | connector | | Summary | 10-circuit PH-series 2.0 mm-pitch top-entry SMT wire-to-board header |
Ships the KiCad symbol, footprint, a color-preserving GLB 3D model, and an adom-lbr JSON (with generated Fusion 360 .lbr).
