RCLAMP0582B

Semtech RCLAMP0582B — low-capacitance TVS diode array for ESD protection of high-speed automotive Ethernet lines (100BASE-T1). Protects the media-side pairs on each T1 port of the Large Automotive Eth Switch Molecule.

Manufacturer: Semtech
Package: SOT-553
Datasheet: https://www.semtech.com/products/circuit-protection/low-capacitance/rclamp0582b

Part of the adom/large-automotive-eth-switch-molecule automotive Ethernet toolboard.

Contents

File	Purpose
`rclamp0582b.kicad_sym`	KiCad schematic symbol
`SOT-416.kicad_mod`	KiCad footprint
`SOT-553.step`	3D model (STEP)
`rclamp0582b.glb`	3D model (GLB, wiki viewer)
`rclamp0582b.adom-lbr.json`	Canonical adom-lbr library JSON
