EVE LF105 Prismatic Battery Molecule

Public Made by Adom

by adom

Adom molecule carrier for the EVE LF105 prismatic LiFePO4 cell (105Ah). Part of the Modular BMS system.

hardwaremoleculebatteryprismaticlifepo4evelf105bms
Overview Files Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity

3D Model

Symbol & Footprint

Schematic Symbol

Open full view ↗

PCB Footprint

Open full view ↗
Contents

EVE LF105 Prismatic Battery Molecule

Adom molecule carrier for the EVE LF105 prismatic LiFePO4 cell (105Ah, 3.2V nominal). Includes integrated current sensing ICs for the BQ76952 BMS.

Features

  • Holds 1x EVE LF105 prismatic cell (105Ah, 3.2V)
  • 2x 7799 current sense ICs for BMS integration
  • 4 machine contact pads + 3 machine connector pads
  • KiCad 8 project with schematic and PCB layout
  • GLB 3D model included

Components

Ref Value Description
IC1, IC2 7799 Current sense IC
MP1-MP4 — Machine contact pads
MC1-MC3 — Machine connector pads

Usage

This molecule is part of the Modular BMS system. An alternative to the 18650 cylindrical cell carriers for applications requiring higher capacity prismatic cells. Monitored by the BQ76952 BMS molecule.

Source

Files

board.glb 3D Model (GLB) Molecule_EVE_LF105_Prismatic.glb 3D Model (GLB) Molecule_EVE_LF105_Prismatic.step STEP CAD Model Molecule_EVE_LF105_Prismatic.kicad_mod KiCad Footprint Molecule_EVE_LF105_Prismatic.kicad_sym KiCad Symbol HERO.md Documentation hero.png Image manifest.json Data File Molecule_EVE_LF105_Prismatic.kicad_pcb KICAD_PCB File Molecule_EVE_LF105_Prismatic.kicad_pro KICAD_PRO File Molecule_EVE_LF105_Prismatic.kicad_sch KICAD_SCH File package.json Data File pcb.svg Vector Image sheet-000.svg Vector Image
