BQ76952 BMS Molecule v2

Adom molecule for the Texas Instruments BQ76952 battery management IC. This is the central controller of the Modular BMS system — it monitors cell voltages, controls charge/discharge FETs, handles cell balancing, and provides comprehensive protection (OV, UV, OCD, SCD).

Features

  • TI BQ76952 battery monitor/protector (3-16S)
  • BQ771807 high-side MOSFET driver
  • BSC160N15NS5 / BSZ900N15NS3 power MOSFETs for CHG/DSG control
  • Cell balancing support
  • Full protection suite: OV, UV, OCD, SCD, OT
  • I2C interface to host MCU (MSP430)
  • Multi-sheet KiCad 8 schematic (Monitor, FETs, Interface, Hardware, PinConfig)

Schematic Sheets

Sheet Contents
BMS029B_Monitor BQ76952 IC, cell voltage sense, thermistors, decoupling
BMS029B_FETs CHG/DSG MOSFET bank, gate drivers, current sense
BMS029B_Interface I2C/UART connectors, MSP430 interface, debug headers
BMS029B_Hardware Board-level: fiducials, mounting, compliance markings
BMS029B_PinConfig Pin configuration and mapping

Key ICs

Ref Value Description
— BQ76952 3-16S battery monitor and protector
— BQ771807DPJR High-side N-FET driver
— BSC160N15NS5ATMA1 150V N-channel MOSFET (power stage)
— BSZ900N15NS3 G 150V N-channel MOSFET (power stage)
— MMBT5401LT1G PNP transistor (gate drive)
— FCX495TA NPN transistor

Usage

This molecule is the brain of the Modular BMS system. It connects to battery carrier molecules (18650 or EVE LF105 prismatic) via cell sense lines and controls charge/discharge through integrated MOSFET banks. An MSP430 host MCU communicates over I2C to configure the BQ76952 and read telemetry.

Source

Files

Molecule_BQ76952 - v2.glb 3D Model (GLB) Molecule_BQ76952_v2.glb 3D Model (GLB) Molecule_BQ76952 - v2.step STEP CAD Model Molecule_BQ76952_v2.kicad_mod KiCad Footprint Molecule_BQ76952_v2.kicad_sym KiCad Symbol BMS029B_FETs.kicad_sch KICAD_SCH File BMS029B_Hardware.kicad_sch KICAD_SCH File BMS029B_Interface.kicad_sch KICAD_SCH File BMS029B_Monitor.kicad_sch KICAD_SCH File BMS029B_PinConfig.kicad_sch KICAD_SCH File HERO.md Documentation hero.png Image manifest.json Data File Molecule_BQ76952 - v2.kicad_pcb KICAD_PCB File Molecule_BQ76952 - v2.kicad_pro KICAD_PRO File Molecule_BQ76952 - v2.kicad_sch KICAD_SCH File package.json Data File sheet-000.svg Vector Image
