18650 Battery Carrier Molecule

Public Made by Adom

by adom

Adom molecule carrier for two 18650 cylindrical lithium-ion cells using Keystone 54 battery holders. Part of the Modular BMS system.

hardwaremoleculebattery18650bmskeystone
Overview Files Packages Releases Dependencies Issues Breadcrumbs Pull Requests Activity

3D Model

Symbol & Footprint

Schematic Symbol

Open full view ↗

PCB Footprint

Open full view ↗
Contents

18650 Battery Carrier Molecule

Adom molecule carrier for two 18650 cylindrical lithium-ion cells. Uses Keystone 54 spring-contact battery holders for reliable cell retention.

Features

  • Holds 2x 18650 cells in series
  • Keystone 54 battery holders with spring contacts
  • 4 machine contact pads for Adom workcell integration
  • KiCad 8 project with schematic and PCB layout
  • STEP 3D model included

Components

Ref Value Description
BT1, BT2 Keystone 54 18650 battery holder with spring contacts
MP1-MP4 — Machine contact pads

Usage

This molecule is part of the Modular BMS system. Connect in series with 18650 Jumper molecules to build battery packs of 3+ cells, monitored by the BQ76952 BMS molecule.

Source

Files

board.glb 3D Model (GLB) Molecule_18650_Battery.glb 3D Model (GLB) Molecule_18650_Battery.step STEP CAD Model Molecule_18650_Battery.kicad_mod KiCad Footprint Molecule_18650_Battery.kicad_sym KiCad Symbol HERO.md Documentation hero.png Image manifest.json Data File Molecule_18650_Battery.kicad_pcb KICAD_PCB File Molecule_18650_Battery.kicad_pro KICAD_PRO File Molecule_18650_Battery.kicad_sch KICAD_SCH File package.json Data File pcb.svg Vector Image sheet-000.svg Vector Image
