LAN9370-I/KCX
Public Made by Adomby adom
Microchip LAN9370-I/KCX — single-port Gigabit TSN Ethernet switch/PHY for automotive & industrial networks. VQFN-64 (8x8x0.9mm, 0.4mm pitch).
Symbol & Footprint
Schematic Symbol
Open full view ↗PCB Footprint
Open full view ↗LAN9370-I/KCX
Microchip LAN9370-I/KCX — single-port Gigabit TSN (Time-Sensitive Networking) Ethernet switch / PHY, targeted at automotive and industrial networks.
| MPN | LAN9370-I/KCX |
| Manufacturer | Microchip |
| Package | VQFN-64, 8×8×0.9 mm, 0.4 mm pitch, exposed pad |
| KiCad symbol | LAN9370-I_KCX:LAN9370-I_KCX |
| KiCad footprint | LAN9370-I_KCX:QFN40P800X800X90-65N |
| Datasheet | https://www.microchip.com/en-us/product/lan9370 |
Assets on this page
LAN9370-I_KCX.kicad_sym— KiCad symbol (from the Microchip/SamacSys ECAD model, Part ID 17294287)LAN9370-I_KCX.pretty/— KiCad footprint library (QFN40P800X800X90-65N)LAN9370-I_KCX.step— 3D model (KiCad stockQFN-64-1EP_8x8mm_P0.4mmpackage model)
Usage
Used by the LAN9370_STM32_Molecule automotive
toolboard. Boards depending on it declare it in package.json:
"dependencies": {
"adom/lan9370-i-kcx": "^0.1.0"
}
Symbol + footprint are the vendor SamacSys export; the 3D is KiCad's stock model for the same VQFN-64 package (the SamacSys bundle did not include a free STEP).
