KSZ9131RNXI — Gigabit Ethernet PHY, RGMII (Microchip)
Public Made by Adomby adom
Microchip KSZ9131RNXI — 10/100/1000BASE-T Gigabit Ethernet PHY with RGMII MAC interface, industrial temp, VQFN-48 (7x7mm). Multi-unit KiCad symbol grouped by function.
Symbol & Footprint
Schematic Symbol
Open full view ↗PCB Footprint
Open full view ↗KSZ9131RNXI — Gigabit Ethernet PHY, RGMII (Microchip)
Microchip KSZ9131RNXI — 10/100/1000BASE-T Gigabit Ethernet PHY, RGMII MAC interface, industrial temp.
| MPN | KSZ9131RNXI |
| Manufacturer | Microchip |
| Package | VQFN-48, 7×7 mm, 0.5 mm pitch, EP |
| KiCad footprint | KSZ9131RNXI:QFN50P700X700X90-49N (SamacSys) |
| 3D | ksz9131rnxi.step (manufacturer model from the SamacSys bundle) |
| Datasheet | https://www.microchip.com/en-us/product/ksz9131 |
Symbol
Multi-unit KiCad symbol organized by function (LAN9374 house style):
| Unit | Group | Pins |
|---|---|---|
| A | POWER / GROUND | 16 |
| B | 1000BASE-T MDI | 9 |
| C | RGMII / MAC | 12 |
| D | MANAGEMENT | 4 |
| E | CLOCK / LED / STRAPS | 5 |
| F | NO CONNECT | 3 |
Pins carry real electrical types (power_in, input, bidirectional, open_collector, no_connect).
