IRL80HS120

Infineon Technologies IRL80HS120 - 80 V, 12.5 A logic-level N-channel power MOSFET, PQFN 2x2 (DFN2020-6).

| Manufacturer | Infineon Technologies | | MPN | IRL80HS120 | | Category | transistor | | Summary | 80 V, 12.5 A logic-level N-channel power MOSFET, PQFN 2x2 (DFN2020-6) |

Datasheet

Ships the KiCad symbol, footprint, a color-preserving GLB 3D model, and an adom-lbr JSON (with generated Fusion 360 .lbr).
