FTSH-107-01-L-DV-K

Samtec FTSH-107-01-L-DV-K - 2x7 (14-pin) 1.27 mm-pitch SMT micro header, Arm Cortex STDC14 debug.

| Manufacturer | Samtec | | MPN | FTSH-107-01-L-DV-K | | Category | connector | | Summary | 2x7 (14-pin) 1.27 mm-pitch SMT micro header, Arm Cortex STDC14 debug |

Datasheet

Ships the KiCad symbol, footprint, a color-preserving GLB 3D model, and an adom-lbr JSON (with generated Fusion 360 .lbr).

Symbol & Footprint

Schematic Symbol

Open full view ↗

PCB Footprint

Open full view ↗
