DT1240A-08LP3810

Diodes Incorporated DT1240A-08LP3810 — 8-channel low-capacitance TVS / ESD protection array in the LP3810 (UDFN-10) package. Protects the 1000BASE-T RJ45 pairs on the Large Automotive Eth Switch Molecule.

Part of the adom/large-automotive-eth-switch-molecule automotive Ethernet toolboard.

Contents

File Purpose
dt1240a-08lp3810.kicad_sym KiCad schematic symbol
UDFN-9_1.0x3.8mm_P0.5mm.kicad_mod KiCad footprint
UDFN-9_1.0x3.8mm_P0.5mm.step 3D model (STEP)
dt1240a-08lp3810.glb 3D model (GLB, wiki viewer)
dt1240a-08lp3810.adom-lbr.json Canonical adom-lbr library JSON

Files

dt1240a-08lp3810.glb 3D Model (GLB) UDFN-9_1.0x3.8mm_P0.5mm.step STEP CAD Model dt1240a-08lp3810.kicad_sym KiCad Symbol UDFN-9_1.0x3.8mm_P0.5mm.kicad_mod KiCad Footprint dt1240a-08lp3810.adom-lbr.json Data File hero.png Image package.json Data File
