CC0402MPX5R5BB225 — 2.2 µF 0402 6.3 V X5R MLCC (YAGEO)
Public Made by Adomby adom
YAGEO CC0402MPX5R5BB225 — 2.2 uF, 6.3 V, X5R, 0402 MLCC ceramic capacitor.
Symbol & Footprint
Schematic Symbol
Open full view ↗PCB Footprint
Open full view ↗CC0402MPX5R5BB225 — 2.2 µF 0402 6.3 V X5R MLCC (YAGEO)
YAGEO CC0402MPX5R5BB225
| MPN | CC0402MPX5R5BB225 |
| Manufacturer | YAGEO |
| Package | 0402 |
| KiCad footprint | Capacitor_SMD:C_0402_1005Metric |
| Datasheet | https://www.mouser.com/datasheet/3/508/1/upy-gphc_x5r_4v-to-50v.pdf |
YAGEO CC0402MPX5R5BB225 — 2.2 uF, 6.3 V, X5R, 0402 MLCC ceramic capacitor.
Used by the LAN9370_STM32_Molecule board. This page is keyed by manufacturer part number (MPN).
