BSS123

Changjing · MOSFETs · SOT-23

BSS123 from Changjing, in a SOT-23. Pinout and pin descriptions extracted from the manufacturer datasheet (extract_pins, cross-checked by a second model); symbol, footprint, and 3D from KiCad-official CAD.

Pinout

Pin Name Type Function
1 GATE input Voltage-controlled gate of the N-channel MOSFET, rated for VGS of ±20 V with a gate threshold of 1 to 2.8 V at VDS = VGS and ID = 250 µA.
2 SOURCE passive Source terminal of the N-channel MOSFET, with continuous source-drain diode current IS rated at 0.17 A.
3 DRAIN passive Drain terminal of the N-channel MOSFET, rated for VDS of 100 V and continuous drain current ID of 0.17 A.

Key specifications

Parameter Value
Manufacturer Changjing
Package SOT-23
Category Transistors/Thyristors
Pins 3

Electrical characteristics

Limits as printed in the datasheet (page.json metadata.characteristics carries them as data).

Parameter Symbol Min Typ Max Unit Conditions Page
Drain-Source Voltage VDS 100 V 1
Gate-Source Voltage VGS -20 20 V 1
Continuous Drain Current ID 0.17 A note 1 1
Pulsed Drain Current IDM 0.68 A tp=10us 1
Continous Source-Drain Diode Current IS 0.17 A 1
Power Dissipation PD 0.35 W 1
Thermal Resistance from Junction to Ambient RθJA 357 ℃/W note 1 1
Junction Temperature TJ 150 ℃ 1
Storage Temperature TSTG -55 150 ℃ 1
Lead Temperature for Soldering Purposes TL 260 ℃ 1/8'' from case for 10 s 1
Drain-source breakdown voltage V(BR)DSS 100 V VGS = 0V, ID =250µA 2
Zero gate voltage drain current IDSS 1 µA VDS =100V,VGS = 0V 2
Zero gate voltage drain current IDSS 10 nA VDS =20V,VGS = 0V 2
Gate-body leakage current IGSS -50 50 nA VGS =±20V, VDS = 0V 2
Gate threshold voltage VGS(th) 1 2.8 V VDS =VGS, ID =250µA 2
Drain-source on-resistance RDS(on) 10 Ω VGS =4.5V, ID =0.17A 2
Drain-source on-resistance RDS(on) 6 Ω VGS =10V, ID =0.17A 2
Forward tranconductance gFS 80 mS VDS =10V, ID =170mA 2
Diode forward voltage VSD 1.3 V IS=340mA, VGS = 0V 2
Input Capacitance Ciss 29 60 pF VDS =25V,VGS =0V,f =1MHz 2
Output Capacitance Coss 10 15 pF VDS =25V,VGS =0V,f =1MHz 2
Reverse Transfer Capacitance Crss 2 6 pF VDS =25V,VGS =0V,f =1MHz 2
Total Gate Charge Qg 1.4 2 nC VDS=10V,ID=0.22A, VGS=10V 2
Gate-Source Charge Qgs 0.15 0.25 nC VDS=10V,ID=0.22A, VGS=10V 2
Gate-Drain Charge Qgd 0.2 0.4 nC VDS=10V,ID=0.22A, VGS=10V 2
Turn-on delay time td(on) 8 ns VGS=10V,VDD=30V, ID=2.8A,RGEN=50Ω 2
Turn-on rise time tr 8 ns VGS=10V,VDD=30V, ID=2.8A,RGEN=50Ω 2
Turn-off delay time td(off) 13 ns VGS=10V,VDD=30V, ID=2.8A,RGEN=50Ω 2
Turn-off fall time tf 16 ns VGS=10V,VDD=30V, ID=2.8A,RGEN=50Ω 2

CAD (KiCad official)

  • Symbol: BSS123
  • Footprint: Package_TO_SOT_SMD:SOT-23
  • 3D model: SOT-23 (KiCad packages3D, STEP)
  • 3D model files: bss123-etched.step / bss123-etched.glb carry the MPN laser-etched on the die in a toggleable Adom.LaserEtch group (Fusion-ready); bss123.step / bss123.glb are the bare package body.

Provenance

Data extracted from the manufacturer datasheet, not a distributor listing:

  • Datasheet: Changjing datasheet (5 pp, sha256 3fedce2e98afaaba, retrieved 2026-10-19, tier: lcsc)
  • Extractor: parts-factory 2.0.0 / extract_pins 0.3, primary claude-haiku-5-5 (text), consensus claude-sonnet-5-5 (agreed), guards: pin_guards 0.1: passed. Pins are checked against the footprint pad set and their cited datasheet pages before publish.
  • CAD: KiCad official libraries (CC-BY-SA 4.0).
